Casting - Magnus Sourcing

★ Why Magnus

The right foundry
for every casting

India is globally recognised as one of the world's largest casting producers, with major foundry clusters in Coimbatore, Rajkot, Kolhapur, Pune, and Ahmedabad serving international markets in automotive, pump & valve, and agricultural applications. The range runs from high-volume grey and ductile iron castings to precision investment castings in stainless and alloy steel — with sand casting and investment casting the most mature, export-ready processes, with established pipelines to the USA, Europe, and the Middle East.

Magnus matches each part to the foundry best suited to its process, material, and volume — then manages sampling, quality inspection, and shipping, so the casting arrives ready to use.

At a Glance

Processes All types of castings

Weight range 50g — 1000kg

Materials Iron, Alum.,SS, Brass, Carbon, Alloy

Lead time 2-4 weeks to first sample

★ Specifications

Process
capabilities.

Specification	Detail
Processes	Investment, sand, pressure die, centrifugal, gravity die, shell mould
Materials	Grey & ductile iron, carbon / stainless / alloy steel, aluminium, brass, bronze
Part size	Minimum Part Size: 10 × 10 × 10 mm (or as per drawing) Maximum Part Size: Up to 2000 × 2000 × 2000 mm
Part weight	Minimum Part Weight: 50 grams Maximum Part Weight: Up to 1000 kg (5 Tons)
Tolerance & finish	As-cast tolerance per ISO 8062-3: investment casting typically DCTG 4–6; sand casting typically DCTG 8–10. Tighter tolerances achieved via machining. Exact tolerance confirmed per drawing and process.
Quality	Inspected at source, documented before dispatch
Export markets	USA, Europe, UAE, UK, Australia

★ WHERE OUR CASTINGS GO

Industries
We Serve

Automotive

Brake components
Hubs
Brackets
Housings

Industrial

Machine bases
Gear housings
Bearing blocks
Frames

Hydraulics

Cylinder bodies
Valve blocks
Manifolds
End caps

Pump & Valvs

Pump casings
Impellers
Valve bodies
Flanges

Oil & Gas

Manifolds
Valve components
Fittings
Housings

Agriculture

Tractor components
Linkage parts
Gearbox housings
Implement castings

★ The Casting Type

Types Of Casting
pick yours.

Investment Casting

Precision, near-net-shape parts with fine detail and excellent surface finish. Best for: complex, high-accuracy components in steel and stainless.

Sand Casting

Versatile and cost-effective across a wide range of sizes. Best for: medium-to-large iron and steel parts.

Pressure Die Casting

High-volume non-ferrous parts with tight repeatability and good finish. Best for: aluminium and zinc components at scale.

Centrifugal Casting

Dense, defect-free walls in cylindrical shapes. Best for: rings, bushings, and pipes.

Gravity Die Casting

Reusable metal moulds for repeatable non-ferrous parts. Best for: medium-volume aluminium parts.

Shell Mould Casting

Fine surface finish and strong dimensional accuracy. Best for: precise iron and steel parts in medium volume.

★ Materials

Alloys &
materials.

IRON

Ductile Iron (60-40-18, 80-55-06)
Grey Cast Iron (ASTM A48 Class 20–60)
High-Strength CGI

Steel

Carbon Steel (ASTM A216 WCB)
Alloy Steel (Cr-Mo, Ni-Cr-Mo)
Stainless (CF8, CF8M, duplex)

Non-ferrous

Aluminum (A356, A380, ADC12, LM6)
Copper & Brass
Bronze

★ FAQs

Questions buyers
ask us first.

What casting processes can Magnus source?

Investment, sand, pressure die, centrifugal, gravity die, and shell mould casting — matched to the part's complexity, material, and volume.

What materials are available?

Grey and ductile iron, carbon, stainless and alloy steel, aluminium alloys, brass, and bronze.

What tolerances and sizes are possible?

Castings are produced to your drawing — from small components to large parts — across all major processes and materials. Exact tolerances and sizes are confirmed per part.

Which markets does Magnus serve?

Castings are exported to the USA, Germany, the UAE, the UK, and Australia, across automotive, industrial, energy, and agricultural applications.

How does it work?

Share a drawing and target volume. Magnus identifies the right foundry, arranges a sample for approval, manages production and handles shipping.

★ Ready to Start?

Get a Quote
in 48 Hours.

Share your drawings and target volume.

Get a Quote →
